| Model | HASPD-1S |
| Electrical Parameters |
| Input Voltage | 12-400V | 400-800V | 400-1000V |
| Input Current | 10A/16A/20A/25A/32A/40A/63A |
| Input Array | 1 | 1 | 1 |
| Breaking Capacity | 4000A | 2000A | 4000A |
| Output Circuit Breaker | 2P | 2P | 4P |
| Output String | 1 | 1 | 1 |
| Lightning Protector Parameters |
| Test Category | Class II protection 8/20μs |
| Nominal Discharge Current | 20kA |
| Maximum Discharge Current | 40kA | 60kA |
| Voltage Protection Level | 4kV | 4kV | 4kV |
| Maximum Continuous Working Voltage | 500V | 1000V | 1000V |
| Number Of Poles | 2P | 2P | 3P |
| Lightning Protection Instructions | Green is normal, red needs to replace the module |
| Structural Features | Plug-in modules - replaceable |
| Box Parameters |
| Protection Class | IP65 |
| Connector | Cable Gland |
| Box Material | Flame Retardant, PC+ABS Plastic, UV-Proof |
| Installation Method | Wall-mounted |
| Operating Temperature | -25°C~+55°C |
| Altitude | 2000 Meter |
| Allowable Relative Humidity | 0~95%, no condensation |
| Box Size(MM) | 140*210*100 | 140*210*100 | 215*210*100 |
